Cummins KTA38-G9 50/60Hz 1100kVA/1250kVA Cummins onan sound proof drawing

900/1000kW 1125/1250kVA@50Hz, 1000/1100kW 1250/1375kVA@60Hz

• Genset Model:

  PC1250/PC1375

• Prime/Standby Power@50Hz:

  900/1000kW 1125/1250kVA

• Prime/Standby Power@60Hz:

  1000/1100kW 1250/1375kVA

• Cylinder *Bore*Stroke/Displacement:

  12×159×159mm/37.8L

• Alternator Style/Model:

  Stamford/SURIRELLA 404E

• Controller Brand/Model:

  DEEPSEA 7320

• Fuel Consumption(50/60Hz):

  248/260L/h @ 100% load

• Coolant/Lubrication/Fuel tank Capacity:

  118/114/1400L

• Open type size/Weight:

  4600*1850*2500mm/7700KGS

• Sound proof size/Weight:

  5800*2200*2550mm/9100KGS
